JBH-400D 柔纸巾、餐巾纸枕式包装机
性能与特点：Performance and feature：1、本机适合于柔纸巾（乳霜纸）、餐巾纸的包装；This machine is suitable for packaging soft tissues(Cream Paper) and napkins;2、整机变频器控制，袋长即设即切，无需调节空走，一步到位，省时省膜。The whole machine is controlled by frequency converter, the bag length is s…
产品介绍:
性能与特点：
Performance and feature：
1、本机适合于柔纸巾（乳霜纸）、餐巾纸的包装；
This machine is suitable for packaging soft tissues(Cream Paper) and napkins;
2、整机变频器控制，袋长即设即切，无需调节空走，一步到位，省时省膜。
The whole machine is controlled by frequency converter, the bag length is set and cut immediately, no need to adjust the empty running, one step is in place, saving time and film.
3、人机界面，参数设定方便快捷；故障自诊断功能，故障显示一目了然。
Man-machine interface, convenient and quick parameter setting; fault self-diagnosis function, fault display at a glance.
4、高感光度电眼色标跟踪，数字化输入封切位置，使封切位置更加准确。
High-sensitivity electric eye color mark tracking and digital input of the sealing and cutting position make the sealing and cutting position more accurate.
5、温度独立 PID 控制，更好适合各种包装材质。
Temperature independent PID control, better suitable for various packaging materials.
6、定位?；δ埽徽车?，不浪费包膜。
ositioned stop function, no sticking to the knife, no wasting of film.
7、所有控制由软件实现，方便功能调整和技术升级，永不落后。
All control is realized by software, which is convenient for function adjustment and technical upgrade, and never lags behind.
Performance and feature：
1、本机适合于柔纸巾（乳霜纸）、餐巾纸的包装；
This machine is suitable for packaging soft tissues(Cream Paper) and napkins;
2、整机变频器控制，袋长即设即切，无需调节空走，一步到位，省时省膜。
The whole machine is controlled by frequency converter, the bag length is set and cut immediately, no need to adjust the empty running, one step is in place, saving time and film.
3、人机界面，参数设定方便快捷；故障自诊断功能，故障显示一目了然。
Man-machine interface, convenient and quick parameter setting; fault self-diagnosis function, fault display at a glance.
4、高感光度电眼色标跟踪，数字化输入封切位置，使封切位置更加准确。
High-sensitivity electric eye color mark tracking and digital input of the sealing and cutting position make the sealing and cutting position more accurate.
5、温度独立 PID 控制，更好适合各种包装材质。
Temperature independent PID control, better suitable for various packaging materials.
6、定位?；δ埽徽车?，不浪费包膜。
ositioned stop function, no sticking to the knife, no wasting of film.
7、所有控制由软件实现，方便功能调整和技术升级，永不落后。
All control is realized by software, which is convenient for function adjustment and technical upgrade, and never lags behind.
技术参数:
|
薄膜宽度 Film width(mm) |
Max.400 |
|
薄膜厚度 Film thickness |
2.5 um-7.0 um OPP 单层膜（可印刷） |
|
制袋长度 Bag length(mm) |
150-330 |
|
制袋宽度 Bag width(mm) |
50-180 |
|
产品高度 Products height(mm) |
Max.80 |
|
膜卷直径 Film roll diameter(mm) |
Max.350 |
|
包装速度 Packing speed |
40-120包/分 40-120bags/min |
|
电源规格 Power supply specifications |
220V，50/60HZ，3Kw |
|
机器尺寸 Machine size(mm) |
长500×宽855×高1450 Length500 × Width855 × Height 1450 |
|
机器重量 Weight |
580kg |
